Sterilization And Fermentation Tank
  • Sterilization And Fermentation Tank
  • Fermentation-Tank

Sterilization And Fermentation Tank For Dairy Products

  • Capacity: 100L--500L
  • Fermentation Temperature: 40-60℃
  • Power: 6kw--36kw

We're here to help:  Easy ways to get the answers you need.

Share With:
  • Specifications
The equipment consists of two tanks: sterilization tank and fermentation tank.
The equipment is divided into cylinder block, cylinder head, mixing paddle, feed inlet and discharge valve, which are made of imported stainless and acid resistant steel 1Cr18Ni9Ti. They are polished in the cylinder body according to the technical conditions of gb741-80, and there is a mixing paddle in it, which plays the role of mixing. There is a cycloidal needle wheel planetary reducer on the top to drive the mixing paddle, which can be installed, disassembled and cleaned. There are two open cylinder heads for cleaning. The bottom of the cylinder is inclined to facilitate venting. The other two feed ports can be connected with the pipeline to facilitate the continuous feeding of various ingredients. There is a discharge port below, which can be installed with a plug valve. After mixing evenly, rotate the handle of the plug valve 90 degrees to discharge the material, and close it after discharging, so as to achieve the purpose of uniform mixing

Sterilization And Fermentation Tank For Dairy Products working video:



Sterilization And Fermentation Tank Technical Parameter:

Volume  100L 150L 200L 300L 500L
Tank Diameter 625mm 625mm 630mm 800mm 1000mm
Tank Height 605mm 620mm 670mm 600mm 650mm
Capacity 10-100kg 10-150kg 10-200kg 10-300kg 10-500kg
Heating Cycle 25-35min 25-35min 25-35min 25-35min 25-35min
Fermentation Temperature 40-60℃ 40-60℃ 40-60℃ 40-60℃ 40-60℃
Material SUS304 SUS304 SUS304 SUS304 SUS304
Voltage 380V/50hz 380V/50hz 380V/50hz 380V/50hz 380V/50hz
Power 6kw 9kw 12kw 24kw 36kw
Tank Weight     70kg
Tank Size 900*750*1370mm 900*750*1370mm 1020*870*1530mm 1200*1000*1650mm 1500*1150*1900mm
